Wishcolor 50KHz-2GHz Malahit-SDR Receiver DSP Radio Receiver 3.5″ Touch Screen With 5000mAh Battery Support Mode AM SSB NFM WFM

(13 customer reviews)
norton

$288.30

  • Red
  • Silver
Clear
Added to wishlistRemoved from wishlist 0
Add to compare

SKU: 1005002654934843 Category:

Malahit-SDR Receiver DSP Radio Receiver Malachite SDR 50KHz-2GHz 3.5" Touch Screen Firmware 1.10c

the packing box is not include from November 11th

Advantages:

1. 3.5-inch capacitive screen

2. Built-in 5000mah lithium battery

3. Built-in telescopic antenna, also support a better external shortwave antenna

Features:

– DSP SDR Receiver for Malahit

– Capacitive touch screen

– Flash via USB cable

– Supported frequency range: 50KHz-2GHz (250MHz-400MHz is blocked by the author)

– Demodulation mode: AM, SSB, NFM, WFM

Product Parameters:

1) The radio is constructed based on the SDR principle, and the function is determined by loaded software

2) The frequency range is from 50KHz-250Mhz and 250Mhz-2000Mhz

3) All types of analog modulation: AM, SSB (LSB USB), NFM, WFM

4) Powerful functions: variable filter width, adaptive noise suppressor, threshold noise suppressor, Noise Blanker(AGC_Equalizer

5) Use fully functional chip msi001

6) Powerful stm32h743 with a clock frequency of 480MHz is applied

7) 3.5-inch IPS display with touch screen

8) There is a built-in UHF

9) Control 2 encoders with buttons and touch screen

10) The power supply is supplied by the external TYPE-C (for Huawei mobile phone) interface, which can be charged by TYPE-C. The internal lithium battery has a large capacity of 5000mAH (suitable for outdoor use)

11) The current consumption when listening to headphones is 300mA

12) Built-in receiving module In order to improve the HF reception on the antenna, an additional board with a source follower has been developed. The board will be built into the standard receiver design

13) Connect to the computer via USB, you can transmit CAT, IQ and audio

14 160 kHz span, with scalability

15) Sensitivity-Under the condition of up to 250MHz, s / w is 0.3μV = 10dB.

16) Due to the characteristics of the msi001 chip used, the dynamic blocking range is about 85dB.

17) With backlight control

18) Built-in telescopic antenna, exclusive design

window.adminAccountId=224223504;

Specification: Wishcolor 50KHz-2GHz Malahit-SDR Receiver DSP Radio Receiver 3.5″ Touch Screen With 5000mAh Battery Support Mode AM SSB NFM WFM

Color

Red, Silver

Brand Name

TZT

Certification

CE

Origin

CN(Origin)

Model Number

50khz-2000Mhz

Name

SDR Receiver

Frequency

50Khz-250Mhz and 400Mhz-2000Mhz

Built in battery

Yes
